H-Beam Steel That Keeps Your Structure Strong and On Schedule
Reliable H-Beam Steel Supplier for Bridges, Shipbuilding and Steel Structure Projects
Choosing the right H-Beam Steel affects more than one part of a project. It affects how a structure carries load, how fast a crew can install it, and how well it holds up over years of use. Xiaolong manufactures H-Beam Steel for contractors, distributors, and industrial buyers who need consistent quality on every order.
Many buyers run into the same problem: steel that looks fine on paper but varies from batch to batch, or a supplier that cannot explain delivery timing until after the order is placed. Xiaolong solves this with standardized production, documented quality control, and a team that can walk through specifications before you commit to an order. Whether you are sourcing for a single project or setting up a long-term supply line, Xiaolong is built to be the steady partner behind your steel structure.
Talk to our technical team to find the right H-Beam Steel specification for your project.
What Sets Xiaolong H-Beam Steel Apart
Engineered for Higher Load Efficiency
Web and flange thickness ratios are calculated to give strong bending resistance without excess material.
Helps reduce total steel weight while keeping the load-bearing capacity your design requires.
Weld-Friendly Steel Composition That Reduces On-Site Risk
Carbon content is controlled to stay in a safe range for on-site welding, lowering the risk of cracking.
Suitable for structures that require reliable weld joints during assembly.
Built to Survive Long-Distance Sea Transport
Surface treatment is applied before shipment to reduce moisture damage inside sea containers.
Fewer rust issues on arrival mean less rework before installation begins.
Tight Tolerance Control You Can Rely On During Installation
Height, width, and thickness are controlled within recognized industry tolerance ranges.
Consistent dimensions mean less on-site cutting or grinding to fit steel components together.
H-Beam Specification Range for Your Project Needs
|
Series |
Size H×B (mm) |
Web Thickness t₁ (mm) |
Flange Thickness t₂ (mm) |
Theoretical Weight (kg/m) |
|
Narrow Flange (HN) |
200×100 |
5.5 |
8 |
21.3 |
|
Narrow Flange (HN) |
400×200 |
8 |
13 |
66.0 |
|
Medium Flange (HM) |
250×250 |
9 |
14 |
71.8 |
|
Medium Flange (HM) |
400×400 |
13 |
21 |
172.0 |
|
Wide Flange (HW) |
700×300 |
13 |
24 |
182.0 |
|
Wide Flange (HW) |
900×300 |
16 |
28 |
233.0 |
Industries and Structures Built with Xiaolong H-Beam Steel
Shipbuilding and Offshore Platform Construction
Used in ship hull sections, deck supports, and welded structural frames.
Selected grades meet low-temperature impact requirements for marine environments.
Bridge Girders and Transportation Infrastructure
Applied in bridge main girders, pier supports, and elevated roadway structures.
Larger sizes, such as 700×300 and above, are common in long-span bridge projects.
Industrial Plant Frames and Heavy Machinery Support
Used for factory columns, equipment foundations, and heavy machinery bases.
Chosen for load stability in facilities with continuous vibration or heavy operating loads.
Multi-Story Steel Structure Buildings
Applied in columns and main beams for commercial buildings and warehouse structures.
Small to medium sizes, from 100×100 to 400×200, cover most civil and industrial building needs.
Common Purchasing Questions for H-Beam Steel
What is the minimum order quantity for Xiaolong H-Beam Steel?
It depends on the size you need. Standard sizes have a lower minimum than custom sizes. Contact us for an exact number.
Can I buy a small quantity for a personal or small-scale project?
Yes. We work with both large buyers and small contractors or workshops. Let us know your scale and we'll suggest the best order size.
Can you produce custom sizes not listed in the table?
Yes. Send us your drawings or required specifications, and we'll confirm feasibility and lead time.
How do you support overseas buyers with shipping and documents?
We prepare standard export documents, such as packing lists and certificates of origin, and advise on sea-freight-ready packaging.
Start Your H-Beam Steel Order With Xiaolong
Whether you need a single batch of standard sizes or ongoing bulk supply for a multi-year project, Xiaolong is ready to support your order from specification to delivery. We provide custom sizing, wholesale pricing for large orders, and documentation support for project tenders. If you are ready to move forward, or just want to compare options before deciding, reach out to our team for a quotation and specification sheet built around your project.
